SWIM Berlin2400 Kombi Welder DC TIG 200 Plus CUT TIG MMA E-Hand Inverter 4 in1
Professional welder with job memory, digital control panel and innovative control.
- DC DC TIG welding
- TIG pulse function - pulse welding
- MMA / ARC Electrode Hand Welding
- Plasma / CUT cutting up to 12 mm
Note: Clutch valve not included
- Garantiebestimmungen: click there to view details.
- VectorDigital product catalogue: click there to view details.
- Data sheet: click there to view details.
- Bedienungsanleitung: click there to view details.
- Technical Details: click there to view details.
- Warranty conditions: click there to view details.
Descript of SWIM Berlin2400 Kombi Welder DC TIG 200 Plus CUT TIG MMA E-Hand Inverter 4 in1
A total solution of precise AC/DC TIG PLUS welding and plasma cutting machine.
Berlin 2400 is the ideal DC TIG welding and Air Plasma Cutting solution for installation, repair and maintenance applications.
Berlin 2400 is built on the base of the DIGITAL system, offers precise and efficient TIG welding process with full DC pulse TIG functions whatever you need.Accurate and refined HF ignition and the necessary control, power and work capacity to reliably complete a variety of professional welding tasks.
Berlin 2400 also comes with a 50A@60% heavy duty cycle plasma cutting power source. What you need for any metal welding or cutting works, you just get this combi machine and it?s all you needs.
Easy operation and full functions: From the control panel allowing fast adjustment of all necessary controls for DC TIG welding with either HF or contact ignition. It?s also very convenient to store or take out the welding parameters from the memory .
Important functions & device information at a glance
Precision Arc Performance:
♦ Pulse control:Built in pulsing functions help to minimize heat input on thin materials, and provide for a faster freezing weld puddle for uphill welding on curved surfaces such as process piping. The TIG pulse also helps moderate filler metal deposition for consistent bead appearance.
♦ High-frequency TIG starting:Makes it easy to establish an arc under a variety of conditions. Enhances quality by minimizing the potential for weld contamination created by tungsten inclusions in the weld.
♦ Refined arc ignition from 5A (optional 3A).
♦ Pilot Arc for superior arc performance and easy start.
♦ HF or Non-HF Arc ignition: reliable plasma arc initiation without high frequency.
♦ Continuous Output Control: focus the arc for different material thickness.
♦ Rapid Arc Restrike: fast cutting through gaps, even expanded metal.
♦ Powerful with heavy duty: 50A @60%.
♦ Hot Start Function reliably ignites the electrode and melts perfectly to ensure the best quality even at the start of the seam.
♦ Arc Force makes it easier to weld large-drop melting electrode types at low current strengths with a short arc in particular.
♦ Fast Spot Arc system simply controls the spot arc parameter and offers a stable arc.
♦ 4T Trigger Hold allows to hold the present current by user until press the trigger again.
♦ Fast, precise, clean arc ignition and arc ending.
♦ 10 channels memory capacity
|Power Source Dimensions||L380mm x W160mm x H405mm|
|Welder Type||Inverter Power Source|
|European Standards||EN 60974-1 / IEC 60974-1|
|Number of Phases||1|
|Nominal Supply Voltage||230V +/- 15%|
|Nominal Supply Frequency||50/60Hz|
|Welding Current Range ( STICK Mode)||10 - 170A|
|Welding Current Range ( TIG Mode)||10 - 200A|
|Welding Current Range (CUT Mode)||20 - 50A|
|Effective Input Current /STICK /TIG||15.4A|
|Maximum Input Current/STICK/ TIG||30.9A|
|Single Phase Generator Requirement||10KVA|
|STICK (MMA) Welding Output, 40℃, 10 min.||170A @ 25%, 26,8V / 85A @ 100%, 23,4V|
|TIG (GTAW) Welding Output, 40℃, 10 min.||200A @ 40%, 18V / 126A @ 100%, 15V|
|Cutting Welding Output, 40℃, 10 min.||50A @ 40%, 96V / 25A @ 100%, 90V|
|Open circuit voltage||73V DC / Plasma 265V DC|
